| Mechanical |
| Dimensions |
99.5 x 97.8 x 33.05 mm (3.92 x 3.85 x 1.30") |
| Weight |
0.215 kg (7.58 oz) |
| Max. TX Power |
22 dBm |
| Speeds |
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps |
| Networking Interface |
Wi-Fi
(1) Gigabit Ethernet WAN
(1) LAN |
| Max. Power Consumption |
9W |
| ESD/EMP Protection |
± 24kV Air/Contact |
| Buttons |
Reset |
| Antennas |
(1) Dual-Band Antenna, Single-Polarity |
| Display |
30.73 mm (1.21") Diagonal, 160 x 64, 142 ppi, Capacitive Touch, Grayscale |
| Wi-Fi Standards |
802.11ac |
| Power Save |
Supported |
| Wireless Security |
WPA2-PSK AES/TKIP |
| Operating Temperature |
-10 to 55° C (14 to 131° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| Certifications |
FCC, CE, IC |
|
| Supported Data Rates (Mbps) |
| 802.11ac |
13 Mbps to 866.7 Mbps (MCS0 - MCS9, VHT 20/40/80) |
| 802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| 802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b |
1, 2, 5.5, 11 Mbps |
| 802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
