| Mechanical |
| Dimensions | 118.3 x 46.8 x 25.8 mm (4.66 x 1.84 x 1.02") |
Weight
Without Mount
With Flat Wall Mount
With 20° Wedge Mount |
130 g (4.59 oz)
178 g (6.28 oz)
200 g (7.05 oz) |
| Enclosure Material | Polycarbonate |
| Mount Materials | Flat Wall Mount: Aluminum Alloy
20° Wedge Mount: Polycarbonate |
| Weatherproofing | IPX4 |
Optics |
| Sensor | 5 MP CMOS Sensor |
| Lens | Fixed Focal Length |
| View Angle | H: 138°, V: 114°, D: 155° |
| Night Mode | Built-in IR LED Illumination and IR Cut Filter |
Video |
| Video Compression | H.264 |
| Resolution | 1600 x 1200 (4:3) |
| Maximum Frame Rate | 30 FPS |
System |
| Processor Specs | Ambarella Advanced Image Processing SoC |
| Memory Information | 512 MB |
| Mangement Interface | UniFi Protect |
| Networking Interface | 802.11 ac Wi-Fi |
| Flash Memory Support | 256 MB |
| Max. Power Consumption | 12VA |
| Power Requirements | 16-24VAC, 20VA |
| Link/Activity LED | Yes |
| Button | Factory Reset |
| Mounting | Flat Wall/20° Wedge (Kits Included) |
| Operating Temperature | -10 to 40º C (14 to 104º F) |
| Operating Humidity | 0 to 90% Noncondensing |
| Certifications | FCC, IC, CE |
Audio |
| Microphone | Yes (Can be Disabled in Software) |
| Speaker | Yes |
Software |
| Controller Software | UniFi Protect |
| Mobile Apps | UniFi Protect iOS and Android |
| Compatible Mechanical Chimes |
Manufacturer
Broan-NuTone
Broan-NuTone
Heath Zenith
Craftmade
Broan-NuTone
Newhouse Hardware | Model
LA126WH
LA11WH
SL-2735
CTPW-RG
LA39WH
CHM3D
|
| Compatible Digital Chimes |
Manufacturer
Broan-NuTone
IQ AMERICA
IQ AMERICA | Model
LA600WH
DW-2850
DW-2840 |
